*Steel-welded construction frame
*With hydraulic motor
*Mobile control panel
*Top roll hydraulic moveable
*One standard combination roller
*Horizontal and vertical operation
Features:
1. Steel-welded construction frame
2. With hydraulic motor
3. Mobile control panel
4. Top roll hydraulic moveable
5. One standard combination roller
6. Horizontal and vertical operation
Specification:
| Model | HRBM65 | |
| Dia. Of roller | ￠65 mm | |
| Power | 2.2kw/3HP | |
| Spindle speed | 9.3r/min | |
| Packing Size | 125x115x180cm | |
| N.W./G.W. | 720/920KGS | |
| Capacity | Size(mm) | Min Dia.(mm) |
 | 80x2540x10 | 600500 |
| | 120x2550x10 | 600400 |
| | 50x5020x20 | 600400 |
| | 80x40x740x40x5 | 500400 |
| | 80x40x740x40x5 | 400360 |
| | 100x50x650x40x5 | 600500 |
| | 100x50x650x40x5 | 600500 |
| | 70x640x5 | 500400 |
| | 70x640x5 | 600500 |
| | ￠50￠20 | 600400 |
| | 70x70x330x30x3 | 900500 |
| | 80x40x3 | 800 |
| 50x30x2 | 500 | |
Standard accessories:
All the above processing capacities can be finished by one set of standard combination roller
Optional accessories:
Special roller:
| Model | HRBM65 | |
| Profile | Size | Min Dia.(mm) |
| | 3-1/2”x2”2-1/8”x2”￠100x2mm￠60x2mm | 9005001000500 |
